This Weird Star System Is Flipping Awesome

The binary system observed by ALMA isn’t wonky, it’s the first example of a polar protoplanetary disk

Artwork of the system HD 98000. This is a binary star comprising two sun-like components, surrounded by a thick disk of material. What’s different about this system is that the plane of the stars’ orbits is inclined at almost 90 degrees to the plane of the disk. Here is a view from the surface of an imagined planet orbiting in the inner edge of the disk [University of Warwick/Mark Garlick].

Some star systems simply don’t like conforming to cosmic norms. Take HD 98000, for example: It’s a binary system consisting of two sun-like stars and it also sports a beautiful protoplanetary disk of gas and dust. So far, so good; sounds pretty “normal” to me. But that’s only part of the story.

When a star is born, it will form a disk of dust and gas — basically the leftovers of the molecular cloud the star itself formed in — creating an environment in which planets can accrete and evolve. Around a single star (like our solar system) the protoplanetary disk is fairly well behaved and will create a relatively flat disk around the star’s spin axis. For the solar system, this flat disk would have formed close to the plane of the ecliptic, an imaginary flat surface that projects out from the sun’s equator where all the planets, more or less, occupy. There are “wonky” exceptions to this rule (as, let’s face it, cosmic rules are there to be broken), but the textbook descriptions of a star system in its infancy will usually include a single star and a flat, boring disk of swirling material primed to build planets.

Cue HD 98000, a star system that has flipped this textbook description on its head, literally. As a binary, this is very different to what we’re used to with our single, lonely star. Binary stars are very common throughout the galaxy, but HD 98000 has a little something extra that made astronomers take special note. As observed by the Atacama Large Millimeter/sub-millimeter Array (ALMA), its protoplanetary disk doesn’t occupy the same plane as the binary orbit; it’s been flipped by 90 degrees over the orbital plane of the binary pair. Although such systems have been long believed to be theoretically possible, this is the first example that has been found.

“Discs rich in gas and dust are seen around nearly all young stars, and we know that at least a third of the ones orbiting single stars form planets,” said Grant M. Kennedy, of the University of Warwick and lead author of the study published today in the journal Nature Astronomy, in a statement. “Some of these planets end up being misaligned with the spin of the star, so we’ve been wondering whether a similar thing might be possible for circumbinary planets. A quirk of the dynamics means that a so-called polar misalignment should be possible, but until now we had no evidence of misaligned discs in which these planets might form.”

Artwork of the system HD 98000. This is a binary star comprising two sun-like components, surrounded by a thick disc of material [University of Warwick/Mark Garlick]

This star system makes for some rather interesting visuals, as shown in the artist’s impression at the top of the page. Should there be a planetary body orbiting the stars on the inner edge of the disk, an observer would be met with a dramatic pillar of gas and dust towering into space with the two stars either side of it in the distance. As they orbit one another, the planetary observer would see them switch positions to either side of the pillar. It goes without saying that any planet orbiting two stars would have very different seasons than Earth. It will even have two different shadows cast across the surface.

“We used to think other solar systems would form just like ours, with the planets all orbiting in the same direction around a single sun,” added co-author Daniel Price of Monash University. “But with the new images we see a swirling disc of gas and dust orbiting around two stars. It was quite surprising to also find that that disc orbits at right angles to the orbit of the two stars.”

Interestingly, the researchers note that there are another two stars orbiting beyond the disk, meaning that our hypothetical observer would have four suns of different brightnesses in the sky.

The most exciting thing to come out of this study, however, is that ALMA has detected signatures that hint at dust growth in the disk, meaning that material is in the process of clumping together. Planetary formation theories suggest that accreting dust will go on to form small asteroids and planetoids, creating a fertile enviornment in which planets can evolve.

“We take this to mean planet formation can at least get started in these polar circumbinary discs,” said Kennedy. “If the rest of the planet formation process can happen, there might be a whole population of misaligned circumbinary planets that we have yet to discover, and things like weird seasonal variations to consider.”

What was that I was saying about “cosmic norms”? When it comes to star system formation, there doesn’t appear to be any.

Reference: https://warwick.ac.uk/newsandevents/pressreleases/double_star_system
Paper:
https://www.nature.com/articles/s41550-018-0667-x

Wonky Star Systems May Be Born That Way

A nearby baby star has been discovered with a warped protoplanetary disk — a feature that may reveal the true nature of the solar system’s planetary misalignments

[RIKEN]

Textbook descriptions of our solar system often give the impression that all the planets orbit the sun in well-behaved near-circular orbits. Sure, there’s a few anomalies, but, in general, we’re led to believe that everything in our interplanetary neighborhood travels around the sun around a flat orbital plane. This, however, isn’t exactly accurate.

Pluto, for example, has an orbit around the sun that is tilted by over 17 degrees out of the plane of the ecliptic (an imaginary flat plane around which the Earth orbits the sun). Mercury has an inclination of seven degrees. Even Venus likes to misbehave and has an orbital inclination of over three degrees. If all the material that built the planets originated from the same protoplanetary disk that was — as all the artist’s impressions would have us believe — flat, what knocked all the planet’s out of alignment with the ecliptic?

Until now, it was assumed that, during the early epoch of our solar system’s planet-forming days, dynamic chaos ruled. Planets jostled for gravitational dominance, Jupiter bullied smaller worlds into other orbits (possibly chucking one or two unfortunates into deep space), and gravitational instabilities threw the rest into disorderly orbital paths. Other star systems also exhibit this orbital disorder, so perhaps it’s just an orbital consequence of a star system’s growing pains.

But there might be another contribution to the chaos: perhaps wonky star systems were just born that way.

Cue a recent observation campaign of the nearby baby star L1527. Located 450 light-years away in the direction of the Taurus Molecular Cloud, L1527 is a protostar embedded in a thick protoplanetry disk. Using the Atacama Large Millimeter/submillimeter Array (ALMA), in Chile, astronomers of the RIKEN Cluster for Pioneering Research (CPR) and Chiba University in Japan discovered that the L1527 disk is actually two disks morphed into one — both of which are out of alignment with one another. Imagine a vinyl record that has been left on a heater and you wouldn’t be far off visualizing what this baby star system looks like.

The RIKEN study, published on Jan. 1 in Nature, suggests that this warping may have been caused by jets of material emanating from the star’s birth, kicking planet-forming material into this warped configuration and, should this configuration remain stable, could result in planets with orbital planes that are significantly out of alignment.

“This observation shows that it is conceivable that the misalignment of planetary orbits can be caused by a warp structure formed in the earliest stages of planetary formation,” said team leader Nami Sakai in a RIKEN press release. “We will have to investigate more systems to find out if this is a common phenomenon or not.”

It’s interesting to think that if this protoplanetary disk warping is due to the mechanics behind the formation of the star itself, we might be able to look at mature star systems to see the ancient fingerprint of a star’s earliest outbursts or, possibly, its initial magnetic environment.

It’s possible “that irregularities in the flow of gas and dust in the protostellar cloud are still preserved and manifest themselves as the warped disk,” added Sakai. “A second possibility is that the magnetic field of the protostar is in a different plane from the rotational plane of the disk, and that the inner disk is being pulled into a different plane from the rest of the disk by the magnetic field.”

Though orbital chaos undoubtedly contributed to how our solar system looks today, with help of this research, we may be also getting a glimpse of how warped our sun’s protoplanetry disk may have been before the planets even formed.

Newborn Star Found Growing Inside Magnetic Nest of Chaos

ProtoStarMagFieldLines
NRAO/AUI/NSF; D. Berry

Conventional wisdom would have us believe that stars form in extremely powerful and ordered magnetic fields. But “conventional,” our universe is not (as Yoda might say).

In a new and fascinating study published in Astrophysical Journal Letters and carried out by astronomers using the Atacama Large Millimeter/submillimeter Array (ALMA) in Chile, a star some 1,400 light-years away in the Serpens star-forming region had its magnetic field gauged.

The star, called Ser-emb 8, is embedded inside the magnetic field passing through the molecular cloud it was born in. As the surrounding dust aligns itself with the direction of these magnetic field lines, ALMA is able to make precise measurements of the polarization of the emissions produced by this dust. From these incredibly sensitive measurements, a map of the polarization of light could be created, providing a view of the magnetic nest the star was born in.

newborn-star
Texture represents the magnetic field orientation in the region surrounding the Ser-emb 8 protostar, as measured by ALMA. The gray region is the millimeter wavelength dust emission. Credit: ALMA (ESO/NAOJ/NRAO); P. Mocz, C. Hull, CfA

And this nest is an unexpected one; it’s a turbulent region lacking the strong and ordered magnetism that would normally be predicted to be in the immediate vicinity of Ser-emb 8. Previous studies have shown newborn stars to possess powerful magnetic fields that take on an “hourglass” shape, extending from the protostar and reaching light-years into space. Ser-emb 8, however, is different.

“Before now, we didn’t know if all stars formed in regions that were controlled by strong magnetic fields. Using ALMA, we found our answer,” said astronomer Charles L. H. “Chat” Hull, at the Harvard-Smithsonian Center for Astrophysics (CfA) in Cambridge, Mass. “We can now study magnetic fields in star-forming clouds from the broadest of scales all the way down to the forming star itself. This is exciting because it may mean stars can emerge from a wider range of conditions than we once thought.”

By comparing these observations with computer simulations, an insightful view of the earliest magnetic environment surrounding a young star has been created.

“Our observations show that the importance of the magnetic field in star formation can vary widely from star to star,” added Hull in a statement. “This protostar seems to have formed in a weakly magnetized environment dominated by turbulence, while previous observations show sources that clearly formed in strongly magnetized environments. Future studies will reveal how common each scenario is.”

Hull and his team think that ALMA has witnessed a phase of star formation before powerful magnetic fields are generated by the young star, wiping out any trace of this pristine magnetic environment passing through the star forming region.

Two Exoplanets Are Whipping-Up a Pretty Protoplanetary Gas Spiral

alma-spirals
ALMA (ESO/NAOJ/NRAO)/Tang et al.

Using the awesome power of the Atacama Large Millimeter/submillimeter Array (ALMA) in Chile, astronomers have probed the protoplanetary disk of a young star system — with a twist.

ALMA is no stranger to protoplanetary disks; the array of 66 radio antennae in the Atacama desert is extremely sensitive to the emissions from the gas and dust surrounding stars. But this observation has revealed something more — there are two obvious dusty rings (orange) that are being sculpted by the presence of massive worlds, but between them (in blue) is a spiral gas structure. If there’s one thing I love it’s space spirals!

When comparing these observations with theoretical modeling of the system — called AB Aurigae, located about 470 light-years away — for that gas spiral to exist, there must be some interplanetary interplay between two exoplanets orbiting the star at 30 and 80 AU (astronomical units, where 1 AU is the average distance that Earth orbits the sun). The spiral is following the direction of rotation of the disk.

Besides looking really pretty, studies of these spiral structures help astronomers identify the presence of exoplanets and build a better understanding of the nature of protoplanetary disks.

ALMA Reveals the True Nature of Hubble’s Enigmatic Ghost Spiral

Appearing as a ghostly apparition in deep space, the LL Pegasi spiral nebula signals the death of a star — and the world’s most powerful radio observatory has delved into its deeper meaning.

170302-graphics3
Left: HST image of LL Pegasi publicized in 2010. Credit: ESA/NASA & R. Sahai. Right: ALMA image of LL Pegasi. Credit: ALMA (ESO/NAOJ/NRAO) / Hyosun Kim et al.

When the Hubble Space Telescope revealed the stunning LL Pegasi spiral for the first time, its ghostly appearance captivated the world.

Known to be an ancient, massive star, LL Pegasi is dying and shedding huge quantities of gas and dust into space. But this is no ordinary dying star, this is a binary system that is going out in style.

The concentric rings in the star system’s nebula are spiraling outwards, like the streams of water being ejected from a lawn sprinkler’s head. On initial inspection of the Hubble observation, it was assumed that the spiral must be caused by the near-circular orbit of two stars, one of which is generating the flood of gas. Judging by the symmetry of the rings, this system must be pointing roughly face-on, from our perspective.

Though these assumptions generally hold true, new follow-up observations by the Atacama Large Millimeter/submillimeter Array (ALMA) on the 5,000 meter-high Chajnantor plateau in Chile has added extra depth to the initial Hubble observations. Astronomers have used the incredible power of ALMA to see a pattern in the rings, revealing the complex orbital dynamics at play deep in the center of the spiral.

“It is exciting to see such a beautiful spiral-shell pattern in the sky. Our observations have revealed the exquisitely ordered three-dimensional geometry of this spiral-shell pattern, and we have produced a very satisfying theory to account for its details,” said Hyosun Kim, of the Academia Sinica Institute of Astronomy and Astrophysics (ASIAA) in Taiwan and lead researcher of this work.

Just as we read tree rings to understand the history of seasonal tree growth and climatic conditions, Kim’s team used the rings of LL Pegasi to learn about the nature of the binary star’s 800 year orbit. One of the key findings was the ALMA imaging of bifurcation in the rings; after comparing with theoretical models, they found that these features are an indicator that the central stars’ orbit is not circular — it’s in fact highly elliptical.

ALMA observation of the molecular gas around LL Pegasi. By comparing this gas distribution with theoretical simulations, the team concluded that the bifurcation of the spiral-shell pattern (indicated by a white box) is resulted from a highly elliptical binary system. Credit: ALMA (ESO/NAOJ/NRAO) / Hyosun Kim et al.

Probably most striking, however, was that Hubble was only able to image the 2D projection of what is in fact a 3D object, something that ALMA could investigate. By measuring the line-of-sight velocities of gas being ejected from the central star, ALMA was able to create a three-dimensional view of the nebula, with the help of numerical modeling. Watch the animation below:

“While the [Hubble Space Telescope] image shows us the beautiful spiral structure, it is a 2D projection of a 3D shape, which becomes fully revealed in the ALMA data,” added co-author Raghvendra Sahai, of NASA’s Jet Propulsion Laboratory in Pasadena, Calif., in a statement.

This research is a showcase of the power of combining observations from different telescopes. Hubble was able to produce a dazzling (2D) picture of the side-on structure of LL Pegasi’s spirals, but ALMA’s precision measurements of gas outflow speed added (3D) depth, helping us “see” an otherwise hidden structure, while revealing the orbital dynamics of two distant stars.

A special thanks to Hyosun Kim for sending me the video of the LL Pegasi visualization!
